Robotic Deflection Mount
2-5 SM-RDM-20000 intRoDuction AnD DeScRiption
The RDM-2000 series deflection mounts come standard
with the items shown in Figure 1. Before starting the
installation, please read and understand the installation
procedure outlined in this manual.
6
5
9
4
3
2 1
7
8
Figure 1: Packaged RDM-2000 Mount
Item No. Description Qty.
1 RDM-2000 Deflection Mount Assembly 1
2 E-Stop Cable Assembly 1
3 Rear Adapter Plate (Aluminum) 1
4 M6 x 1 x 16mm Flat Head Socket Cap Screw 5
5 4mm Hex Wrench 1
6 3 mm Hex Wrench 1
7 3/16” x 3/16” x ½” Long Keystock 1
8 Air Fitting (Accepts 5/32” tubing) 1
9 M4 x 60mm Socket Head Cap Screws 6
NOTE
RDM adapter plate used to adapt the RDM
mount to the robot arm are sold separately.
Refer to Section 4, pages 10-14, to ensure the
RDM adapter plate is correct for your specific
robot.
