Robotic Deflection Mount
4-14 SM-RDM-2000 ReplAceMent pARtS
Robot Type Robot
Model No.
AdapterPart
No.
AdapterStock
No. Type Ø A B° C Ø D
OTC
DIAHEN
DR 500 RDM-AP-8 3500-1147 A 1.575”
40,01mm
45° .650”
16,51mm
1.937”
49,20mm
RDM-AP-2 3500-1141 A 1.575”
40,01mm
22.5° .525”
13,34mm
1.937”
49,20mm
DR 4200 RDM-AP-8 3500-1147 A 1.575”
40,01mm
45° .650”
16,51mm
1.937”
49,20mm
RDM-AP-2 3500-1141 A 1.575”
40,01mm
22.5° .525”
13,34mm
1.937”
49,20mm
DR 3000 RDM-AP-7 3500-1146 A 1.265”
32,13mm
45° .650”
16,51mm
1.579”
40,11mm
PANASONIC AW5A RDM-AP-12 3500-1116 B 1.968”
49,99mm
45° .525”
13,34mm
1.571”
39,90mm
AW6A RDM-AP-12 3500-1116 B 1.968”
49,99mm
45° .525”
13,34mm
1.571”
39,90mm
AW10A RDM-AP-12 3500-1116 B 1.968”
49,99mm
45° .525”
13,34mm
1.571”
39,90mm
AW5C RDM-AP-12 3500-1116 B 1.968”
49,99mm
45° .525”
13,34mm
1.571”
39,90mm
AW6AL RDM-AP-12 3500-1116 B 1.968”
49,99mm
45° .525”
13,34mm
1.571”
39,90mm
VR 005 RDM-AP-12 3500-1116 B 1.968”
49,99mm
45° .525”
13,34mm
1.571”
39,90mm
VR 006 RDM-AP-12 3500-1116 B 1.968”
49,99mm
45° .525”
13,34mm
1.571”
39,90mm
VR 006L RDM-AP-12 3500-1116 B 1.968”
49,99mm
45° .525”
13,34mm
1.571”
39,90mm
VR 008 RDM-AP-12 3500-1116 B 1.968”
49,99mm
45° .525”
13,34mm
1.571”
39,90mm
VR 16 RDM-AP-12 3500-1116 B 1.968”
49,99mm
45° .525”
13,34mm
1.571”
39,90mm
REIS RV6 RDM-AP-17 3500-1123 B 1.968”
49,99mm
45° .650”
16,51mm
1.236”
31,39mm
RV6L RDM-AP-17 3500-1123 B 1.968”
49,99mm
45° .650”
16,51mm
1.236”
31,39mm
RV-16 RDM-AP-20 3500-1177 B 2.480”
62,99mm
45° .650”
16,51mm
1.888”
47,96mm
RH30-16 RDM-AP-20 3500-1177 B 2.480”
62,99mm
45° .650”
16,51mm
1.888”
47,96mm
STAUBLI RX90 RDM-AP-8 3500-1147 A 1.575”
40,01mm
45° .650”
16,51mm
1.937”
49,20mm
RDM-AP-2 3500-1141 A 1.575”
40,01mm
22.5° .525”
13,34mm
1.937”
49,20mm
