TRANSTIG 300Pi
INSTALLATION, OPERATION AND SETUP 3-16 Manual 0-5309
Programming Parameter Control Panel Display
Base Current
This parameter sets the STICK weld
current.
Range is 5 to 300A. Factory default
is 120A.
(Pulse)
A-12116 Arc Force
Arc Force is effective when in STICK
mode only. Arc Force control provides
an adjustable amount of Arc Force
(or "dig") control. This feature can
be particularly beneficial in providing
the operator the ability to compensate
for variability in joint fit-up in certain
situations with particular electrodes.
In general increasing the Arc Force
control toward 100% (maximum Arc
Force) allows greater penetration
control to be achieved.
Range is 0 to 100%. Factory default
is 30%.
(Pulse)
A-12117
3.09 Factory Reset
To perform a Factory Reset, press and hold the Trigger Mode Button while turning on the mains power. All
welding parameter will be restored to the factory setting.
Art # A-12118_AB
Figure 3-8
