TRANSTIG 300Pi
INSTALLATION, OPERATION AND SETUP 3-12 Manual 0-5309
DC Pulse Mode / DC mode
This parameter selects DC PULSE
operating mode or DC
operating mode.
Adjust the multi function control knob
to change between DC Pulse and DC
modes.
Range is DC or DC Pulse Mode.
Factory default is DC.
This shows Panel display for DC
operating mode.
Note that the display -nP stands for
Non Pulse mode which is DC operating
mode.
This Shows Panel display for DC Pulse
operating mode.
Note that the display --P stands for DC
Pulse Mode.
(Pulse)
(Pulse)
A-12106
Base Current
In DC TIG mode, this parameter sets
the TIG welding current. In PULSE TIG
mode, this parameter sets the PEAK
current.
Range is 5 to 315A. Factory default
is 120A.
(Pulse)
A-12107
Trough Current
This parameter sets the TIG TROUGH
current when in DC Pulse operationg
mode. The lowest point in the pulse is
called the Trough.
Range is 5 to base current level.
Factory default is 80A.
(Pulse)
