Section 7: disassembly procedure, 01 safety precautions for disassembly, 02 case removal – Tweco 130i Transarc Service Manual User Manual
Page 61: Section 7, Disassembly procedure -1, Safety precautions for disassembly -1, Case removal -1
Manual 0-5282 7-1
DISASSEMBLY PROCEDURE
TRANSARC 130i
7.01 Safety Precautions for Disassembly
!
!
Read and follow safety information in Section 6.02 before proceeding.
Unplug unit before beginning Disassembly procedure.
7.02 Case Removal
!
Read and follow safety information in Section 6.03 before proceeding with disassembly
1. Unscrew 12 Screws to disassemble two parts of case. Remove the case.
1
1
1
1
SECTION 7:
DISASSEMBLY PROCEDURE
