arc master 175 te oPeration
Operation 4-2 Manual 0-5116
4.03 Front Panel
Front Panel
The welding power source is protected by a self re-setting thermostat. The indicator will illuminate if the duty
cycle of the power source has been exceeded. If the Over Heat light illuminates wait for the Over Heat light to
extinguish before resuming welding.
A A R R C C M M A A S S T T E E R R
175TE
LIFT TIG
TRIGGER
LATCH HF TIG
MANUAL ARC NORMAL
PROCESS
ARC FORCE / DOWN SLOPE
(D) Process Selection Switch
(E) Welding Current
Control
Negative Output Terminal Positive Output Terminal
(C) Trigger Mode Selection Switch
(G) Gas Outlet
Art # A-08670
(F) Arc Force/Down
Slope Control
(I) Torch Trigger Socket
(B) Over Heat Indicator
(A) Power On Indicator
Figure 4-1: 175 TE Control Panel
