introDuction arc master 175 te
Manual 0-5116 2-1 Introduction
SECTION 2:
INTRODUCTION
2.01 How to Use This Manual
This Operating Manual applies the part numbers
listed on page i. If none are underlined, they are all
covered by this manual. To ensure safe operation,
read the entire manual, including the chapter on safety
instructions and warnings. Throughout this manual,
the word WARNING, CAUTION and NOTE may appear.
Pay particular attention to the information provided
under these headings. These special annotations are
easily recognized as follows:
!
WARNING
Gives information regarding possible
personal injury. Warnings will be enclosed
in a box such as this.
CAUTION
Refers to possible equipment damage.
Cautions will be shown in bold type.
NOTE
Offers helpful information concerning
certain operating procedures. Notes will
be shown in italics.
2.02 Equipment Identification
The unit’s identification number (specification or part
number), model, and serial number usually appear
on a nameplate attached to the machine. Equipment
which does not have a nameplate attached to the
machine is identified only by the specification or part
number printed on the shipping container. Record
these numbers for future reference.
2.03 Receipt of Equipment
When you receive the equipment, check it against the
invoice to make sure it is complete and inspect the
equipment for possible damage due to shipping. If
there is any damage, notify the carrier immediately to
file a claim. Furnish complete information concerning
damage claims or shipping errors to the location
in your area listed in the inside back cover of this
manual. Include all equipment identification numbers
as described above along with a full description of the
parts in error.
2.04 Description
ArcMaster 175 TE
This compact heavy duty, inverter welding machine
has infinitely adjustable welding current from 5 to
175 amps. It runs standard general purpose .098"
(2.5mm) electrodes for light gauge work, generally
less than .118" (3.0mm) thick, and 1/8" (3.2mm) or
.157" (4.0mm) electrodes for heavier material. The
unit also has a lift TIG and HF TIG function that offers
stable TIG welding characteristics when used with a
suitable TIG torch and shielding gas.
2.05 Packaged Items
• 175 TE Inverter Power Source
• Electrode Holder with 5m Lead (16mm
2 )
• Work Clamp with 5m Lead (16mm 2 )
• TIG Torch
• TIG Torch Accessories
• Plastic Tool Case
• Operating Manual
