Tweco XTTM-301 - Manual (Page 82)

APPENDIX A-8 Manual 0-4768
Stainless Steel
100A
H35 Plasma / N2 Secondary
Art # A-06746
Tip
35-1272
Electrode Shield Cap
35-1034 35-1062 35-1080 35-1041
Cartridge
Shield Cup
35-1016
Plasma Gas Distributor Shield Gas Distributor
35-1020
Shield
(N2)
(ga) (in) (in) Ball psi psi (volts)
(in)
±0.005
(ipm) (in) (sec)
3/8 0.375 45 90 35 142 0.130 50 0.250 0.5
1/2 0.500 45 90 35 145 0.130 37 0.250 0.5
5/8 0.625 45 90 35 153 0.140 26 0.250 0.6
3/4 0.75 45 90 35 155 0.160 20
1 1.00 45 90 35 165 0.160 10
Shield
(N2)
Ball bar bar (volts)
(mm)
±0.125
(mm/min) (mm) (sec)
45 6.2 2.4 143 4.1 1000 6.4 0.5
45 6.2 2.4 151 4.1 740 6.4 0.6
45 6.2 2.4 156 4.1 460
45 6.2 2.4 164 4.1 270 Edge Start
100A SS (H35/N2)
Edge Start
Edge Start
Edge Start
Torch
Working
Height
Travel
Speed
Initial
Piercing
Height
Material
Thickness
Pierce
Delay
Material
Thickness
** Arc
Voltage
Cut Flow Rates / Pressures
Plasma (H35)
Bold Italic type indicates edge starts only.
(mm)
25
20
15
12
** Arc
Voltage
Cut Flow Rates / Pressures
Plasma (H35)
Torch
Working
Height
Travel
Speed
Initial
Piercing
Height
Pierce
Delay
