APPENDIX 7A: PAKMASTER 50XL PLUS SYSTEM DATA
(HAND TORCH)
Cut Quality on Various Materials and Thicknesses
The following table defines the cut quality on various
materials and thicknesses:
Cut Quality on Various Materials
Material Type of Type of Cut
Thickness Material Gas Characteristics
Gage
to
1/2 inch
( 12.7 mm )
Good - Excellent
Good
Good
Air
Air
Carbon Steel
Stainless
Aluminum
Air
Description of Cut Characteristics:
Excellent - Minimum bevel (0 - 4°), minimum kerf (2 x tip
orifice diameter), little or no dross, smooth
cut surface.
Good - Slight bevel (0 - 10°), slightly wider kerf (2-1/2 x
tip orifice diameter), some dross (easily removed),
medium - smooth cut surface, slight top edge
rounding.
Cutting Range
Material Mild Steel
Production Cut:
Up to 1/4 inch - 6.3 mm
Speed 45 ipm / 1.14 mpm
Genuine Cut:
Up to 1/2 inch - 12.7 mm
Speed 12-14 ipm / 0.3 - 0.36 mpm
Severance Cut:
Up to 3/4 inch - 19 mm
Speed 5-7 ipm 0.13 - 0.18 mpm
Pierce Rating
Material Mild Steel
Thickness:
Hand Cutting 1/2 inch - 12.7 mm
Machine Cutting 1/4 inch - 6.4 mm
Transfer Distance 3/8 inch - 9.5 mm
Gouging
Width 3/16 inch - 4.8 mm
Depth 1/8 inch - 3.2 mm
Number Passes Single
Speed 20 ipm / 0.5 mpm
Bevel Cut Capability
Degrees 0° to 45°
Material Thickness 3/8 inch - 9.5 mm
Gas Requirement
Type Gas Air
Operating Pressure 65 psi / 4.5 bar
Max Input Pressure 125 psi / 8.6 bar
Total Flow Rate:
Cutting 350 scfh / 165 lpm
Gouging 230 scfh / 108.5 lpm
Torch Specifications For
PakMaster 50XL Plus Power Supply
Output
Range
Depth Width
Tip A 40 Amps Max. Shallow Narrow
Tip B 40-100 Amps Deep Narrow
Tip C 40-100 Amps Moderate Moderate
Tip D 40-100 Amps Shallow Wide
Gouging Profiles
Application Electrode
Starter
Cartridge
Tip
Shield
Cup Body
Shield Cap
or Deflector Shield Cup
Drag Cutting 9-8215 9-8213 9-8207 (40A) None None 9-8218
9-8215 9-8213 9-8208 (40A) None None 9-8218
9-8215 9-8213 9-8208 (40A) 9-8237
9-8244 or
9-8243
None
Gouging 9-8215 9-8213
Tip A: 9-8225 (40A Max)
Tip B: 9-8226 (40-100A)
Tip C: 9-8227 (40-100A)
Tip D: 9-8228 (40-100A)
9-8237 9-8241 None
SL60 - SL100 Hand Torch Consumables for 40-Amp Power Supply
