Tweco Merlin 6000 Slave PS User Manual
Page 44
APPENDIX
A-10
Manual 0-2570
APPENDIX 8: QUICK REFERENCE TO INTERCONNECTING
CABLES AND HOSES
C abl e/Ho s e D i amet er
C abl e
D es cr i pt i o n
C at al o g #
I nches
mm
A
Power S upply CNC Cable
25 ft (7.6 m)
8-3380
3/8
9.5
50 ft (15.2 m)
8-3381
3/8
9.5
75 ft (22.9 m)
8-3382
3/8
9.5
100 ft (30.5 m)
8-3383
3/8
9.5
B
R emote Control Cable
25 ft (7.6 m)
9-5961
1/2
13
50 ft (15.2 m)
9-5962
1/2
13
75 ft (22.9 m)
9-5963
1/2
13
100 ft (30.5 m)
9-5964
1/2
13
C
R emote Gas S elect Cable
25 ft (7.6 m)
9-4579
1/2
13
50 ft (15.2 m)
9-4580
1/2
13
75 ft (22.9 m)
9-4581
1/2
13
100 ft (30.5 m)
9-4582
1/2
13
D
Arc S tarter Control Cable
35 ft (10.7 m)
9-6901
1/4
6
50 ft (15.2 m)
9-6902
1/4
6
75 ft (22.9 m)
9-6903
1/4
6
100 ft (30.5 m)
9-6904
1/4
6
125 ft (38.1 m)
9-6905
1/4
6
E
Pos itive Pilot S upply Cable
35 ft (10.7 m)
9-6906
1/4
6
50 ft (15.2 m)
9-6907
1/4
6
75 ft (22.9 m)
9-6908
1/4
6
100 ft (30.5 m)
9-6886
1/4
6
115 ft (35.1 m)
9-6857
1/4
6
125 ft (38.1 m)
9-6909
1/4
6
F
Plas ma or S econdary Gas Hos e # 4
10 ft (3.0 m)
9-6910
1/2
13
15 ft (4.6 m)
9-6911
1/2
13
20 ft (6.1 m)
9-6912
1/2
13
25 ft (7.6 m)
9-6913
1/2
13
30 ft (9.1 m)
9-6914
1/2
13
35 ft (10.7 m)
9-6915
1/2
13
40 ft (12.2 m)
9-6916
1/2
13
50 ft (15.2 m)
9-6917
1/2
13
75 ft (22.9 m)
9-6918
1/2
13
100 ft (30.5 m)
9-6919
1/2
13
125 ft (38.1 m)
9-6920
1/2
13
G
Coolant Hos e # 8
35 ft (10.7 m)
9-6921
7/8
22
50 ft (15.2 m)
9-6922
7/8
22
75 ft (22.9 m)
9-6923
7/8
22
100 ft (30.5 m)
9-6924
7/8
22
115 ft (35.1 m)
9-6858
7/8
22
125 ft (38.1 m)
9-6925
7/8
22
H
T orch (-) Cable
25 ft (7.6 m)
9-6892
3/4
19
35 ft (10.7 m)
9-6926
3/4
19
50 ft (15.2 m)
9-6927
3/4
19
75 ft (22.9 m)
9-6928
3/4
19
100 ft (30.5 m)
9-6896
3/4
19
115 ft (35.1 m)
9-6856
3/4
19
125 ft (38.1 m)
9-6929
3/4
19
I
Work Cable
25 ft (7.6 m)
9-6892
3/4
19
35 ft (10.7 m)
9-6926
3/4
19
50 ft (15.2 m)
9-6927
3/4
19
75 ft (22.9 m)
9-6928
3/4
19
100 ft (30.5 m)
9-6896
3/4
19
115 ft (35.1 m)
9-6856
3/4
19
125 ft (38.1 m)
9-6929
3/4
19
J
Parallel Cable 8 ft (2.4 m)
9-6800
1/2
13
Parallel Cable 30 ft (9.1 m)
9-6997
1/2
13
K
CNC Cable
5 ft (1.5 m)
9-4483
5/8
16
10 ft (3.0 m)
9-4484
5/8
16
15 ft (4.6 m)
9-4485
5/8
16
20 ft (6.1 m)
9-4486
5/8
16
25 ft (7.6 m)
9-4486-25
5/8
16
30 ft (9.1 m)
9-4486-30
5/8
16
50 ft (15.2 m)
9-4486-50
5/8
16
