CUTMASTER A40
Manual 0-4978 SERVICE 5-7
Art # A-07989
1
2
3 4
5
6mm
5. Remove the fitting from the filter element assembly
by inserting a 6 mm hex wrench into the internal hex
fitting and turning it counter clock-wise (left). Numbers
4 and 5 in the previous illustration.
6. Disconnect the input line from the filter element as-
sembly.
7. Remove the filter element assembly through the rear
opening.
NOTE
If replacing or cleaning just the filter element refer
to the following illustration for disassembly.
Art # A-07990
Filter Element
8. Install the new or cleaned assembly by reversing these
procedures.
9. Turn ON the air supply and check for leaks before
reinstalling the cover.
