PAGE 4 CHAMPION SL20 PUMP OPERATION / MAINTENANCE MANUAL
2 INSTALLATION
2.1 UNPACKING
After unpacking, the pump should be checked for any damage that may have
occurred during shipment. Damage should be reported to the carrier
immediately.
The following items should be included within the shipping container:
Qty Item Description
1 SL20 Champion SL20 Slurry/Booster Pump
1 MSL20 Operation/Maintenance Manual
2 DP-C-12 End-of-Stroke Probe
1 PC20 Pump Controller **
**Controller equipped with 12-ft. pump interconnect air line package.
2.2 UTILITIES / HOOK-UP FOR CHAMPION SL20 PUMP
It is recommended that the pump be installed no more than 15° from level to
maintain its self-priming ability and pumping efficiency. This pump mounts on a
quick release base for easy installation. We recommend 1/4 - 20 x 3/4” flat head
counter sink screws.
Air Inlet: 2 each 1/4” OD (6mm) Tube (Pump Air Supply).
2 each 5/16” OD (8mm) Tube (Vacuum Generator Supply).
Fluid Ports: 2 each 3/4” OD Flare Tube Port.
Exhaust: Muffler Standard w/2 each 1/2” NPTF (optional) upon removal of
muffler media.
Sensor: 2 each DP-C-12 EOS probes and seals
