PAGE 20 CHAMPION SL20 PUMP OPERATION / MAINTENANCE MANUAL
4.5 PARTS LIST
ILL
NO PART NO QTY DESCRIPTION MATERIAL
1 98002891 2 Fitting, Flare, EL, 3/4RFTx3/4RF PFA
2 98002904 2 Fitting, Flare, Tee,
3/4T x 3/4RF x 3/4T PFA
3 AS004 2 Check, Discharge, SL20 PTFE
4 98001415 4 Check Ball, 3/4” Diameter PTFE
5 98002334 4 O-Ring, -312 PTFE
6 AS006 4 Seal, 1.5 x .62 x .06 PTFE
7 AS005 2 Check, Suction, SL20 PTFE
8 AS003 1 Body, Pump, SL20 PTFE
9 1700C0047 4 Diaphragm, Maxim 50 PTFE
10 W0151 2 Target, 2.5 Diameter PTFE
11 AS007 2 Head, Remote, SL20 PP
12 AK097 2 Washer, Slip, M50 PTFE
13 AK003 2 Nut, Union, Maxim 50 PP
14 AK030 2 Seal, Pilot Cap, Maxim PTFE
15 AM009 2 Cap, Pilot, Maxim 25 PP
16 98003260 4 Fitting, MC, Black, 1/2T x 1/4P PP
17 AK182 4 Transfer Tube PFA
18 98003314 2 Screw, 1/4-20 x 1.25 PP
19 98003235 4 Screw, 1/4-20 x .50 PP
20 AS023 1 Panel, Muffler, Baffled PP
21 98003315 2 Spacer, 3/8 x 1/4 x 3/4L PP
22 AS026 4 Pad, Muffler, SL20 PP
23 AS027 3 Baffle, Muffler, SL20 PE
24 AK088 1 Base, Mounting, Molded, M50 PP
25 AK108 1 Lever, Large, Molded PP
26 98003071 1 SCR, Nat, 10-32 x .250 PP
27 98003286 2 Fitting, MC, White, 5/16T x 1/4P PP
28 AS032 2 Fitting, Restrictor PP
29 AS012 2 Cap, QE, CMP, Remote PP
30 W0116 2 Seal, Pilot Cap PTFE
31 98003047 2 Seal, QE VITON
32 AS011 2 Adapter, QE UHMW
33 98003285 2 Insert, Vacuum Generator PEEK
34 AS024 1 Base, CMP, Remote PP
NS DP-C-12 2 End-of-Stroke Probe
Replace item 15.
PP / PTFE
NS W0154 2 Seal, Probe (included in DP-C-12)
Replace item 14. PTFE
