PAGE 14 CHAMPION SL20 PUMP OPERATION / MAINTENANCE MANUAL
Booster Pump Maximum Performance
Performance Curves at 80 psi Supply Pressure
0
10
20
30
40
50
60
70
80
0 2 4 6 8 10 12
Outlet Flow (gpm)
Disch
arg
e Pressu
re (
p
si)
Inlet Pressure
15 psi 10 psi 5 psi
Figure 3-44: Pressure & Capacity Chart
NOTE: Test information is based on specific conditions and limited sampling.
Use for general reference only.
NOTE: Maximum flow of pump in booster applications is 12 GPM or 45 LPM @
15 PSIG (.1 MPa) inlet supply.
