PAGE 18
CHAMPION SL20 PUMP OPERATION / MAINTENANCE MANUAL
4.2 RECOMMENDED SPARE PARTS
KRSL20U-00-B Spares Rebuild Kit, which includes:
Part No Qty Description
KMSL20U-00-B 1 Maintenance Kit
Includes: (4)
(4)
(4)
98001415
98002334
AS006
Check Ball, PTFE
O-Ring, PTFE, -312
Seal, PTFE, 1.5x.82
KDSL20-00-B 1
Diaphragm Kit
Includes: (4)
(2)
1700C0047
W0151
Diaphragms
Fiber Optic Target
1700C0047 4
Diaphragm,
M50
W0151
2
Fiber Optic Target
98003047
2
Seal, Quick Exhaust
AS026 4
Muffler
Pad
In critical applications, a spare pump is recommended to minimize possible down
time during service intervals.
4.3 TOOLS
The following tool kit is recommended as standard service equipment.
KTSL20-00-B Tool Kit, which includes:
Part No Qty Description
98003108
1
Torque Wrench, 30-150 ft/lb., 1/2” Drive
98003150 1
Tool
Case
98003305 1
Drive
Handle
98003306 1
15/16”
Wrench
T0129 1
Strap
Wrench
T0145
1
Check Assembly Tool
T0148
1
1/2” Pin Tool
T0149
1
¾” Optic Cap Pin Tool
T0153 1
Rebuild
Fixture
