tekmar 530 Thermostat Installation - Manual (Page 27)

27 of 28 © 2011 D 530 - 12/11
Technical Data
tekmarNet ® 2 Thermostat 530; One Stage Heat, One Stage Cool, One Fan
Packaged weight 0.8 lb. (380 g)
Enclosure NEMA 1, white PVC plastic
Dimensions 2-7/8” H x 2-7/8” W x 13/16” D (73 x 73 x 21 mm)
Approvals CSA C US, meets Class B: ICES and FCC Part 15
Ambient conditions Indoor use only, 36 to 122°F (2 to 50°C).
RH max 80% up to 88°F (31°C) decreasing linearly to 50%
RH at 104°F (40°C)
Altitude 0 - 6560 feet (2000 m), Installation Category II,
Pollution Category 2
Power supply Provided by tekmarNet ® 2 Control, 1.3 VA
Y and G Relays 24 V (ac) 2 A
