Remote Display Module (RDM)

An optional Remote Display Module can be connected to the 363 if an RTU is not used. All items displayed on the 363 menu will also
be displayed on the remote module. Adjustments can be made from the Remote Display Module. This module is connected to the
control through two wires and has the same physical appearance as an RTU.

The type of setback override that is in effect. This menu and item
can only be viewed if the

Setback / None

DIP switch is set to

Setback

.

NONE, TMPY Occ, PERM
Occ, TMPY UnOcc, PERM
UnOcc, AWAY

363 RTU Schd (Schedule) Menu

Item

LT

D

USER

Range

None

– No override.

TMPY Occ

– Overrides to Occupied setting for 3 hours.

PERM Occ

– Overrides to Occupied setting until

new override is selected.

TMPY Unocc

– Overrides to Unoccupied for 3 hours.

PERM Unocc

– Overrides to Unoccupied setting

until new override is selected.

AWAY

– Room & WWSD temperature at 62

°F (17°C), no DHW.

˚F, ˚C

363 RTU Misc (Miscellaneous) Menu

Item

LT

D

USER

Range

062 063

OFF, 30 sec, ON

ADV, INST, USER, LTD

The operating mode for the back lighting of the LCD and the time
until the control returns to the view menu after any button was
pressed.

If

Backlight is set to

OFF

,

the control returns after 10

seconds and the backlight stays off.

If Backlight is set to

30 SEC

,

the control returns after 30 seconds and the backlight stays on for
30 seconds after any button press.

If Backlight is set to

ON

,

the

control returns after 90 seconds and the backlight stays on.

The access level that is to be used by the RTU.
DIP switch =

Only qualified service people should adjust items in the

ADV

(Advance)

and

INST

(Installer) access levels.

The units of measure that all of the temperatures are to be displayed
in by the RTU.

The highest outdoor air temperature recorded since this item was
last cleared. To clear this item, press and hold the and buttons
until ‘CLR’ is displayed.

363 RTU Monitor Menu

Item

LT

D

USER

Range

062 063

The lowest outdoor air temperature recorded since this item was
last cleared. To clear this item, press and hold the and buttons
until ‘CLR’ is displayed.

The lowest room air temperature recorded since this item was last
cleared. To clear this item, press and hold the and buttons until
‘CLR’ is displayed.

The highest room air temperature recorded since this item was last
cleared. To clear this item, press and hold the and buttons until
‘CLR’ is displayed.

-67 to 149˚F
(-55 to 65˚C)

14 to 167˚F
(-10 to 75˚C)

-67 to 149˚F
(-55 to 65˚C)

14 to 167˚F
(-10 to 75˚C)

Note: Depending on the settings the installer makes in the control, certain menu items may not appear.

The desired room air temperature during an Occupied period for this
mixing zone. In LTD access level, this setting can only be adjusted

±3°F (±1°C).

Occ

UnOcc

The desired room air temperature during an UnOccupied period for
this mixing zone.In LTD access level, this setting can only be adjusted

±3°F (±1°C).
The minimum temperature desired at the slab sensor while the
control is not in WWSD. This item can only be viewed if a tekmar
slab sensor is connected to a RTU 063.

35 to 100˚F
(2 to 29˚C)

35 to 100˚F
(2 to 29˚C)

OFF, 35 to 120˚F
(2 to 49˚C)

363 RTU Adjust Menu

Item

LT

D

USER

Range

062 063

All specifications are subject to change without notice.

Printed in Canada. U 363 -06/99.
