Copyright © 1999 U 363 -06/99
2 of 4
-31 to 266˚F
(-35 to 130˚C)
Current DHW tank temperature as measured by the DHW tank
sensor.
•
•
Current outdoor air temperature as measured by the outdoor sensor.
This is the default display for the control.
-67 to 149˚F
(-55 to 65˚C)
•
•
Target room air temperature. “— — —” denotes no heat is required.
Will not display if RTU is connected.
- - -, 35 to 100˚F
(2 to 38˚C)
•
Measured room air temperature at the indoor sensor. Will not display
if RTU is connected.
-58 to 167˚F
(-50 to 75˚C)
•
•
Current mixed supply water temperature as measured by the
mixing sensor.
-31 to 266˚F
(-35 to 130˚C)
Current boiler supply water temperature as measured by the boiler
sensor.
•
Current storage tank water temperature as meassured by the storage
tank sensor.
-31 to 266˚F
(-35 to 130˚C)
•
•
Target DHW tank temperature. This item can only be viewed if a
tekmar sensor is used to measure the DHW tank temperature.
- - -, OFF, 70 to 190˚F
(21 to 88˚C)
•
-31 to 266˚F
(-35 to 130˚C)
•
363 View Menu
Range
Item
LT
D
USER
Note: Depending on the settings the installer makes in the control, certain menu items may not appear.
•
•
•
•
The desired room air temperature during an Occupied period for
mixing zone(s). Will not display if RTU is connected. In LTD access
level, this setting can only be adjusted
±3°F (±1°C).
35 to 100˚F
(2 to 38˚C)
35 to 100˚F
(2 to 38˚C)
The desired room air temperature during an UnOccupied period for
mixing zone(s). Will not display if RTU is connected.
OFF, 35 to 120˚F
(2 to 49˚C)
The minimum temperature at the slab sensor, provided the control
is not in Warm Weather Shut Down. This item can only be adjusted
if a tekmar sensor is connected.
•
Mixing Water Temperature Setback. The amount that the mixing
supply temperature will be reduced when the control is in an
UnOccupied mode.
0 to 50˚F
(0 to 28˚C)
363 Adjust Menu
Item
Range
LT
D
USER
Occ
UnOcc
35 to 100˚F
(2 to 38˚C)
The desired room air temperature during an Occupied period for the
boiler zones in the heating system.
In LTD access level, this setting can only be adjusted
±3°F (±1°C).
35 to 100˚F
(2 to 38˚C)
0 to 50˚F
(0 to 28˚C)
The desired room air temperature during an UnOccupied period for
the boiler zone(s) in the heating system.
Boiler Water Temperature Setback. The amount that the boiler supply
temperature will be reduced when the control is in an
UnOccupied mode.
•
•
•
•
•
•
The DHW storage tank’s temperature during the Occupied period.
This item can only be adjusted if a tekmar sensor is used to measure
the DHW tank temperature.
The DHW storage tank’s temperature during the UnOccupied
period.This item can only be adjusted if a tekmar sensor is used to
measure the DHW tank temperature.
OFF, 70 to 190˚F
(OFF, 21 to 88˚C)
OFF, 70 to 190˚F
(21 to 88˚C)
Occ
UnOcc
Occ
UnOcc
•
The system’s warm weather shut down during the Occupied period.
The system’s warm weather shut down during the UnOccupied period.
35 to 100˚F, OFF
(2 to 38˚C)
35 to 100˚F, OFF
(2 to 38˚C)
Occ
UnOcc
•
