5. TRANSMITTER SPECIFICATIONS
________________________________________________________________________________________________________________________
Parameter Specifications
Level Output
Measured Variable Liquid Level (as determined by location of magnetic float)
Full Range 18” to 300”
Non-Linearity Full Span 0.020 F.S. or 1/32”, whichever is greater
Repeatability 0.01% F.S. or 1/32”, whichever is greater
Sensor Operating Temp. - 40°F to 300°F
Transmitter Loop
Input Voltage Range 10.5 to 36.1 VDC
Reverse Polarity Protection Series Diodes
Safety Approval CSA Certified Explosion Proof C1.I, Grps. B, C, D C1.II Grps E, F, G
Division 1, NEMA 4X
CSA Certified Intrinsically Safe (when installed with I.S. Barriers)
C1. I, Grps A, B, C, D; C1. II, Grps, E, F, G. Division 1, NEMA 4X
Calibration
Zero Adjust Range Anywhere within the active length
Span Adjust Range Full scale more than or equal to 0.5” from zero
Environmental
Electronics Operating Temp. - 30°F to 160°F
Humidity 0 to 100% Relative Humidity
Materials/Outer Pipe 316 Stainless Steel
Field Installation
Mounting 3/4” NPT fitting or flange mounting
Wiring 2 wire connection, shielded cable or twisted pair to screw terminals
through a 3/4” NPT conduit opening
Display
Measured Variables Liquid Level
Update Rate: 3 seconds
Size: 0.5”
Number of digits: 16
Measurement: % of span, a 4-20 mA output or any unit of measure
HART® Communications
Method of Communication Frequency Shift Keying (FSK) conforms with Bell 202 Modem
Standards with respect to baud rate and digital “1” and “0” frequencies
Baud Rate 1200 bps
Digital “0” Frequency 2200 Hz.
Digital “1” Frequency 1200 Hz.
Data Byte Structure 1 Start Bit, 8 Data Bits, 1 Odd Parity Bit, 1 Stop Bit
Digital Process Structure Rate Poll//Response Model 2.0 per second
