GBC 2064WF-1 Operation Manual
© 2009 General Binding Corporation an ACCO Brands CO. Page 25
OPTIONAL
SEPERATOR BAR
ROLL TO ROLL OPTION
OUTPUT
KRAFT
PAPER
OPTION
THERMAL
FILM
CUSTOM WEB PATH #1
CUSTOM WEB PATH #2
FIGURE 36
FIGURE 37
FIGURE 38
Tips for AccuShield
1. Load the laminator as illustrated in Fig. 36.
2. You must have the Separator bar option to
accurately run this material. See your Sales Rep
for ordering the Separator Bar.
3. Set Top Temp to 280*F(135*C) and a speed
setting no greater than 4.
4. Liner rewind tension will be greater than normal
operating standard
5. To prevent some adhesive adhering to the rollers,
you may choose to use a roll of craft paper for a
Carrier.
Use the blank space below and blank diagrams to
Note your tips and web paths for your Special
applications.
TIPS FOR CUSTOM APPLICATION #1 (Fig. 37)
1.
2.
3.
4.
TIPS FOR CUSTOM APPLICATION #2 (Fig. 38)
1.
2.
3.
4.
5.
