GBC 2064WF User Manual

Page 20

GBC 2064WF-1

Operation Manual

FIGURE 25

FIGURE 26

Start Laminating

1. At this point you should have your laminator

webbed with the appropriate material for your
application.

2. The feed table should be in the normal operating

position.

3. Close the main and Pull roll nips. Rollers should

be closed.

4. Speed is set to 3 or less and front () motor

direction is selected.

5. Press the start ( ) button.

6. Set main roller pressure between 40% – 60% for

laminating by turning the main roll lift handle.

CAUTION: If using PSA film, an air pocket may
form between the main rollers and pull rollers.
Raise the pull rollers to allow the air Pocket to
pass.

7. Make any necessary film brake tension

adjustments, pull/main roller pressure, and
clutch and/ or rewind brake tension adjustments.

8. Position the item to be laminated on the feed

table.

9. Align the leading edge of the item parallel to the

heat roller nip (Fig. 25).

10. Use both hands to force the image outward and

slowly push inward toward the nip of the heat
rollers (Fig. 26).

CAUTION: Avoid forcing the image into the
main roller nip as this action will cause the
corners of the leading edge to buckle and create a
wave.
