GBC 2064WF-1

Operation Manual

SEQUENCE OF OPERATIONS Diagram #1

GBC U.S 2064WF-1

Effect of Fiber Optics on sequence of operation

Modes

Situation 1

Situation 2

Situation 3

Machine Run Mode

Normal operation
(No Interruption to any
safety circuitry & Fiber
optic beam)

High speed.

Interrupted optic beam
or opened any safety
circuitry.

Optic beam cleared + all safety
circuitries are closed

Control panel:
Forward Speed: Zero to
Max.
Press “Run” push button
to switch over from foot
switch to the control
panel.

Machine stops Instantly.
Use foot pedal to override
@ 3f/m.

Machine will remain stationary until
run switch is pressed.
Push RUN button switch to run machine
again (Normal operation) mode.

Forward Mode
Press push button
forward switch

Foot switch:
Forward Speed: Zero to
Max.
Note:

Press foot pedal

to change mode and
take over from control
panel at preset speed.

Machine Runs @
3f/m.
(Automatic override from
high to low voltage)

Machine still remains at low voltage
speed of 3f/m.
Steps required to run at (various speed):
The operator will have two choices,

Choice A:
1. Release foot pedal to stop machine.
2. Press foot pedal again to start
machine at original preset control panel
knob speed (pot).

Choice B:
1. Press and hold “Run” push button
switch on the control panel while foot is
still on pedal.
2. Release foot pedal.
3. Adjust speed using “speed knob”

Reverse speed

Zero to

Max.
Press “Run” push button
to switch over from Foot
switch to the Control
panel.

Machine stops Instantly.
Use Foot pedal to
override @ 3f/m.

Machine must not run. It will remain
stationary.
Push RUN button switch to run machine
again at Normal operation mode.

Reverse Mode
Press Reverse
Push button switch.

Reverse speed

Zero to

Max.
Note: Press foot pedal
to change mode and
take over from control
panel.

Machine Runs @ 3f/m.
(Automatic override from
high to low voltage)

Choice B:
1. Press and hold “Run” push button
switch on the control panel while foot is
still on pedal.
2. Release foot pedal.
3. Adjust speed using “speed knob”
