Average Voltage (depending on cell count) x Continuous Current = Continuous Input Watts
Average Voltage (depending on cell count) x Max Burst Current = Burst Input Watts
HINT: The typical average voltage under load of a Ni-Cd/Ni-MH cell is 1.0 volt. The typical average voltage under load of a Li-Po cell is 3.3 volts. This means
the typical average voltage under load of a 10 cell Ni-MH pack is approximately 10 volts and a 3 cell Li-Po pack is approximately 9.9 volts. Due to variations
in the performance of a given battery, the average voltage under load may be higher or lower. These however are good starting points for initial calculations.
Model: 25-size aerobatic/3D airplane
Estimated Flying Weight w/Battery: 4.1 lbs
Total Input Watts Required for Desired Performance: 533 (minimum)
Motor: Power 32
Max Continuous Current: 42A*
Max Burst Current: 60A*
Cells (Li-Po): 3
3 Cells, Continuous Power Capability: 9.9 Volts (3 x 3.3) x 42 Amps = 416 Watts
3 Cells, Max Burst Power Capability: 9.9 Volts (3 x 3.3) x 60 Amps = 594 Watts
Per this example, the Power 32 motor (when using a 3S Li-Po pack) can deliver up to 594 watts of input power, readily capable of powering a 25-size
aerobatic/3D airplane with the desired level of performance (requiring 533 watts minimum). You must however be sure that the battery chosen for power can
adequately supply the current requirements of the system for the required performance.
Battery Choices:
We recommend Thunder Power Li-Po batteries for the best performance and lowest weight (in some cases Ni-MH 1800-2200mAh high-discharge packs also
make good alternatives at the expense of weight and lower capacity). Some examples of the packs we recommend for use with the Power 32 motor can be
found below:
THP33003SPL2
3300mAh 3-Cell/3S 14.8V 20C PL V2 Li-Po EFLB32003S 3200mAh 3S 11.1V 20C Li-Po, 13 AWG
THP33004SPL2 3300mAh 4-Cell/4S 14.8V 20C PL V2 Li-Po EFLB32004S 3200mAh 4S 14.8V 20C Li-Po, 13 AWG
THP33003SP30 3300mAh 3-Cell/3S 11.1V Pro Power 30C Li-Po
THP33004SP30 3300mAh 4-Cell/4S 14.8V Pro Power 30C Li-Po
THP38503SP30 3850mAh 3-Cell/3S 11.1V Pro Power 30C Li-Po
THP38504SP30 3850mAh 4-Cell/4S 14.8V Pro Power 30C Li-Po
Examples of Airplane Setups:
Please see our web site for the most up-to-date information and airplane setup examples.
NOTE: All data measured at full throttle. Actual performance may vary depending on battery and flight conditions.
E3D 25-size
Option 1:
Motor: Power 32
ESC: E-flite 60A Pro SB Brushless ESC (EFLA1060)
Prop: APC 15x8E (APC15080E)
Battery: Thunder Power PRO LITE 6000mAh 3S3P (Note – old battery, substitute THP38503SP30)
Flying Weight w/Battery: 3.5 lbs
Amps
Volts Watts Input Watts/Pound RPM
46.0 10.4 480 137 5880
Expect strong power for unlimited aerobatics and 3D flying. Speed is good and vertical is strong. There is plenty of power for any aerobatic and 3D
maneuvers. Average duration is approximately 12-18 minutes depending on throttle management.
E-flite Diamante 25e (EFL4050)
Option 1:
Motor: Power 32
ESC: E-flite 60A Pro SB Brushless ESC (EFLA1060)
Prop: APC 13x6.5E (APC13065E)
Battery: 3850mAh 4-Cell/4S 14.8V Pro Power 30C Li-Po (THP38504SP30)
Flying Weight w/Battery: 4.1 lbs
Amps
Volts Watts Input Watts/Pound RPM
55 14.4 792 193
Expect excellent power for unlimited aerobatics. Speed is great with strong vertical.
Accessories and Spare Parts:
See our web site at www.E-fliteRC.com or www.horizonhobby.com for our complete line of brushless motors. We have posted a specification comparison
sheet on our web site so you can compare the different motors we offer.
EFLA110
Power Meter (measures power output in amps, volts, watts, and capacity)
EFLA241 Gold Bullet Connector Set, 3.5mm (3)
EFLA249 Gold Bullet Connector Set, 4mm (3)
EFLM1925 Prop Adapter w/ Collet, 5mm
EFLM40321 Shaft: Power 32 BL Outrunner
EFLM40462 X-Mount/Hardware:Power 32/46/60
EFLA1060 60A Pro SB Brushless ESC
