Features
• Superior peak prediction circuitry ensures maximum battery life
• High-efficiency direct current/rising voltage exchange mode minimizes heat output
• Large LCD display indicates mAh, voltmeter, and ammeter
• DC fan for efficient cooling
• LED display with three-color functions indicates charge, discharge and trickle modes
• Reverse polarity protection
• Push-button Start
• Charge beeper indicates when charge is complete
• Banana plugs with alligator clips adapter included
• Receiver, transmitter, BEC- and Tamiya-style charge leads included
Specifications
• 12V DC-powered or 110V AC-powered
• Charges, trickle charges and discharges 1–14 cell packs
• Ni-Cd and Ni-MH compatible
• Voltage booster to DC 28V
• 7.5 amp fuse safety circuit
• Variable charge rates: 200mA–5A (13- and 14-cell packs may not reach 5A)
• 16-bit processor with high-resolution displays features
Functions/LCD Screen Readings
Operation LED Condition/Beep Function
Push Once Red/Beep Once Fast Charge
Push Twice Orange & Red/Beep Twice Cycle (Charge After Discharge)
Push Three Times Orange/Beep Three Times Discharge
Connect Battery Without Pushing Green Trickle Charge (150 mA)
Push One More Time After Action Green Return to Trickle Charge
Error Modes
The Pinnacle+ features a self-diagnostic mode with the following error codes:
• “ERR1” A short circuit or the safety fuse is burned out
• “ERR2” An error has occurred in the charging process (loose connection, contacts or current is adjusted after
the initial 30-second start up mode)
• “ERR6” The peak charge is abnormal because the voltage is too low
• “ERR” The power supply is insufficient (below 10V)
Note : “ERR6” and “ERR” will only occur when using a 12V power source. To cancel error modes, disconnect the
batteries from the charger.
Supplying DC Power to the Pinnacle+
The Pinnacle+ is powered by connecting it to a 12V DC power source, such as a 12V sealed battery (HAN102),
a 12V automobile battery (car must be not be running) or through your field box power panel. The battery capacity
must be over 5Ah.
The Pinnacle+ can also be powered from a standard 110V AC outlet.
12V DC connections:
Step 1 . Attach the red (positive) banana plug to the red (positive) terminal on your 12V battery or power panel.
Step 2 . Attach the black (negative) banana plug to the black (negative) terminal. Alligator clips have been included to
power your charger with a 12V hobby battery. Once your charger is given power, it will beep once and the LCD
will show 28V when voltmeter is selected, which is normal.
2
