E-flite 3-Cell LiPo Balancing Charger, 0.8A User Manual
Page 4
10
Input.power.for.the.charger.can.also.be.supplied.through.the.use.of.an.AC.to.DC.adapter/power.supply.for.
convenient.charging.anywhere.an.AC.outlet.is.available ..We.recommend.the.optional.E-flite
®
.AC.to.12V.DC,..
1 .5-Amp.Power.Supply.(EFLC4000) . NEVER attempt to power the charger from an AC outlet without the
use of a proper AC to DC adapter/power supply.
Note:.When.using.the.AC.to.DC.adapter/power.supply,.the.charger.is.protected.to.prevent.damage.if.the.alligator.
clips.touch ..However,.please.take.care.to.ensure.that.the.alligator.clips.do.not.cause.shorting.of.the.battery,.
adapter/power.supply,.etc ..by.keeping.them.clear .
The.charger.is.equipped.with.two.LED.indicators.marked.RED.and.GREEN.on.the.label ..These.LEDs.indicate.the.
following.(also.found.on.the.label.of.the.charger):
• Red Flashing LED Only:.Input.power.with.no.battery.connected
•. Red and Green Solid LED:.Battery.connected.and.charging
•. Red Solid LED Only:.Charge.complete
•. Red and Green Flashing LED:.Charge.error
