E-flite Eratix 3D 25e ARF Assembly Manual
Landing Gear Installation
Required Parts
• Fuselage
• Main landing gear
• Wheel pant (left & right)
• 2
3 /
4
-inch (70mm) wheel (2)
• 4-40 x 1/2-inch socket head screw (2)
• #4 washers (6)
• 4mm locknut (4)
• 4mm x 35mm machine screw (2)
• 2mm x 8mm wood screws (4)
Required Tools and Adhesives
• Phillips screwdriver (small)
• Needle-nose pliers
• Nut driver: 7mm
• Hex wrench:
3 / 32
-inch
 1. Place the landing gear onto the bottom of the fuselage.
Attach with two 4-40 x 1/2-inch socket head screws and
two #4 washers.
