Wing Installation
Required Parts
• Wing • Fuselage
• Belly pan
Required Tools and Adhesives
• Phillips screwdriver
 1. Place the wing onto the fuselage. Make sure to
pass the Y-Harness lead through the opening in
the fuselage.
 2. Place the belly pan onto the wing and fuselage.
The mounting plate at the rear of the belly pan
keys into the fuselage mounting plate. Use the
screw at the front to secure the belly pan and
wing to the fuselage.
14
