2 E-flite Sukhoi SU-26m 480 ARF Assembly Manual
Contents of Kit/Parts Layout
Replacement Parts
EFL2851 Wing Set
EFL2852 Fuselage w/Hatch
EFL2853 Tail Set
EFL2854 Wing Tube
EFL2855 Landing Gear Set
EFL2857 Pushrod Set
EFL2858 Canopy Hatch
EFL2859 Cowling
EFL2860 Canopy
EFL2862 Hardware Pack
EFLA222 Foam Park Wheels,
1 3 /
4
-inch (45mm)
Covering Colors
HANU973 Lite Scale White
HANU877 Orange
HANU847 Pearl Purple
Introduction
In the world of competition aerobatic airplanes, the
Russian Sukhoi SU-26m is the equivalent of a top fuel
dragster that can turn on a dime. Its combination of
absurd amounts of horsepower, light weight, rugged
construction and amazing agility allows aggressive
pilots to perform to the limits of their physical
endurance.
E-flite perfectly captures the essence of this aerial hot
rod with its Sukhoi SU-26m – a scaled-down version of
the Hangar 9 Sukhoi SU-26m designed by world-class
IMAC competitor Mike McConville. The E-flite SU-26m
features an exceptionally lightweight airframe that was
designed around the powerful Park 480 BL outrunner
motor (sold separately). As with the full-scale Sukhoi,
this combination of lightweight construction and
prodigious power gives the E-flite SU-26m unlimited
performance that is ideally suited for 3D aerobatics.
Important Information
Regarding Warranty Information
Please read our Warranty and Liability Limitations
section on Page 24 before building this product. If you
as the Purchaser or user are not prepared to accept the
liability associated with the use of this Product, you are
advised to return this Product immediately in new and
unused condition to the place of purchase.
Using the Manual
This manual is divided into sections to help make
assembly easier to understand, and to provide breaks
between each major section. In addition, check boxes
have been placed next to each step to keep track
of its completion. Steps with a single circle () are
performed once, while steps with two circles ( )
indicate that the step will require repeating, such as for
a right or left wing panel, two servos, etc.
Remember to take your time and follow the directions.
Table of Contents
Introduction ............................................................... 2
Important Information Regarding
Warranty Information ............................................ 2
Using the Manual ....................................................... 2
Contents of Kit/Parts Layout ........................................ 2
Covering Colors ......................................................... 2
Recommended Radio Equipment ................................. 3
Optional Accessories .................................................. 3
Brushless Outrunner Setup .......................................... 3
Required Tools and Adhesives ..................................... 3
Note on Lithium Polymer Batteries ............................... 3
Warning .................................................................... 3
Landing Gear Installation ............................................ 4
Optional Wheel Pants Installation ................................ 5
Outrunner Motor Installation ....................................... 5
Cowling Installation .................................................... 7
Aileron Hinging ......................................................... 8
Aileron Servos and Linkages ....................................... 9
Wing Installation ...................................................... 12
Stabilizer and Elevator ............................................. 12
Rudder and Fin ........................................................ 16
Rudder and Elevator Servos ...................................... 18
Final Assembly ......................................................... 21
Control Throws......................................................... 22
Center of Gravity ..................................................... 22
Preflight ................................................................... 23
Range Test Your Radio .............................................. 23
Flying Your Sukhoi SU-26m 480 ............................... 23
Safety Do’s and Don’ts for Pilots ................................ 24
Safety Precautions .................................................... 24
Age Requirements .................................................... 24
Warranty Information ............................................... 24
CE Compliance Information for the
European Union.................................................. 26
2008 Official Academy of
Model Aeronautics Safety Code ........................... 26
