Model 5600SE Downflow

28

Service Instructions (Cont’d.)

Seal and Spacer Replacement

To replace seals and spacers, refer to

Replacing Brine Valve, Injectors and Screen

, steps 1–3.

1. Remove the control valve back cover. Remove the control valve front cover. Disconnect the meter dome signal wire from

the front cover and feed it back through the control.

2. Remove screw and washer at drive yoke. Remove timer mounting screws. The entire timer assembly will now lift off

easily. Remove end plug retainer plate.

3. Pull upward on end of piston rod yoke until assembly is out of valve. Remove and replace seals and spacers.

4. Take piston assembly and push piston into valve by means of the end plug. Twist yoke carefully in a clockwise direction

to properly align it with drive gear. Replace end plug retainer plate.

5. Place timer on top of valve. Be sure drive pin on main gear engages slot in drive yoke.

6. Replace timer mounting screws. Replace screw and washer at drive yoke.

7. Return bypass or inlet valving to normal In Service position. Water pressure automatically builds in the conditioner.

NOTE: Be sure to shut off any bypass line.

8. Replace the control valve back cover.

9. Follow

Injectors/Screen Replacement

, steps 9–12.

Meter Replacement

To replace meter refer to

Replacing Brine Valve, Injectors and Screen

, steps 1–3.

1. Remove two screws and clips at bypass valve or yoke. Pull resin tank away from plumbing connections.

2. Pull meter module out of control valve.

3. Remove signal wire from meter module, (snap tab on end opposite wire cable).

4. Apply silicone lubricant to four new o-rings and assemble to four ports on new meter module.

5. Install signal wire into new meter module.

6. Assemble meter to control valve. Note, meter portion of module must be assembled at valve outlet.

7. Push resin tank back to the plumbing connections and engage meter ports with bypass valve or yoke.

8. Attach two clips and screws at bypass valve or yoke. Be sure clip legs are firmly engaged with lugs.

9. Return bypass or inlet valving to normal In Service position. Water pressure automatically builds in the conditioner.

NOTE: Be sure to shut off any bypass line.

10. Check for leaks at all seal areas.

11. Follow

Injectors/Screen Replacement

, steps 9–12.
