Watts 2300 - Manual (Page 4)

Part 3" 4"
Adjusting Screw 05-04867-00 05-04869-00
Adjusting Screw Locknut 05-02945-00 05-02946-00
Spring Button 05-01046-00 05-01047-00
Spring Chamber 04-01414-00 04-01417-00
Adjusting Spring (10-40 psi) 05-05115-01 05-05155-00
Adjusting Spring (30-80 psi) 05-05148-00 05-05150-00
Coupling Nut 05-03019-00 05-03020-00
Pressure Plate 04-03647-00 04-03649-00
Diaphragm 05-01612-00 05-01614-00
Diaphragm Bolts 05-04777-00 05-04782-00
Base 04-00459-00 04-00461-00
Stem Coupling 04-09487-00 04-01496-01
Diaphragm Nut 05-02875-00 05-02877-00
Dowel Pin 05-03865-00 05-03867-00
Stem 04-05343-00 04-05346-00
Body - ANSI NPT Scr – –
Body - ANSI 125 Fig 04-00918-00 04-00920-00
Body - ANSI 250 Fig 04-00928-01 04-00930-00
Sealing Ring 05-04038-00 05-04045-00
Guide Ring 04-04407-00 04-04411-01
Balanced Piston 04-09481-00 –
Balanced Piston Assembly – 22445
Seat Ring 04-04177-01 04-04180-02
Composition Disc 05-01719-00 05-01721-00
Composition Disc Holder 04-09493-00 04-09494-00
Stem Nut 05-03017-00 05-03018-00
Blind Flange Gasket 05-02367-00 05-02369-00
Blind Flange 04-02183-00 04-02186-00
Blind Flange Nut 05-02862-00 05-02860-00
Blind Flange Studs 04-05448-00 04-10119-00
Range Tag (10-40 psi) 05-06221-00 05-06221-00
Range Tag (30-80 psi) 05-06222-00 05-06222-00
Part 3" 4"
Repair Kit 33167 33168
Repair Kits
Part No. By Valve Size
