Small pressure regulators, For residential and commercial applications, Sizes: 26a
Series 26A, 263A
Small Pressure Regulators
Sizes: 26A:
1
⁄
8
" –
1
⁄
2
" (3 – 15mm)
263A:
1
⁄
4
" –
1
⁄
2
" (8 – 15mm)
Series 26A, 263A Small Pressure Regulators are general
purpose pressure regulators for water and no. 2 fuel oil.
These regulators are ideal for use in beverage dispensers,
ice cube machines, paint sprayers, humidifiers and other
similar applications.
Features
• Rugged forged brass body
• Tee handle adjustment
• Oversized orifice
Models
26A 2-way regulator
263A 3-way regulator
Materials
Body:
Brass
Spring Cage: Aluminum
Disc:
Buna-N stainless steel
Diaphragm: Reinforced Buna-N
Pressure – Temperature
Temperature Range: 0°F – 140°F (-18°C – 60°C)
Maximum Working Pressure: 300psi (21 bars)
Reduced Pressure Range:
Options
G Pressure gauge
SS All stainless steel construction
X Slotted adjusting screw
For Residential and Commercial Applications
ES-26A/263A
Job Name –––––––––––––––––––––––––––––––––––––––––––
Contractor ––––––––––––––––––––––––––––––––––––––––––––
Job Location –––––––––––––––––––––––––––––––––––––––––
Approval –––––––––––––––––––––––––––––––––––––––––––––
Engineer –––––––––––––––––––––––––––––––––––––––––––––
Contractor’s P.O. No. –––––––––––––––––––––––––––––––––––
Approval –––––––––––––––––––––––––––––––––––––––––––––
Representative ––––––––––––––––––––––––––––––––––––––––
26A
2-Way
263A
3-Way
Capacity
Model
Size (DN)
A
C
Weight
in.
mm
in.
mm
in.
mm
lbs
kgs
26A
1
⁄
8
3
2
1
⁄
8
54
4
3
⁄
8
111
1 .45
26A/263A
1
⁄
4
8
2
1
⁄
8
54
4
3
⁄
8
111
1 .45
26A/263A
3
⁄
8
10
2
1
⁄
8
54
4
3
⁄
8
111
1 .45
26A/263A
1
⁄
2
15
2
1
⁄
8
54
4
3
⁄
8
111
1 .45
Dimensions – Weights
Dimensions – Weights
C
A
1
2
3
4
5
6
7 gpm
3.8
7.6
11
15
19
23
27 lpm
Flow
Initial pressure 100psi (6.9 bars)
Reduced
Pr
essur
e
bars psi
3.4 50
2.8 40
2.1 30
1.4 20
.7 10
0
0
Suffix
Range
Std. Set at
psi
bars
psi
bars
A
1 – 25
0.1 – 1.7
10
0.7
B
3 – 50
0.2 – 3.4
15
1.0
C
10 – 125
0.7 – 8.6
25
1.7
D
50 – 175
3.4 – 12.1
50
3.4
ES-26A/263A 0407
