Page 6
LED 1
LED 2
Node Status
(flashing green)
Radio Link Ok
(flashing red)
(flashing red)
Device Error
(flashing red, 1 per 3 sec)
No Radio Link
Modbus Register Table
I/O
Modbus Holding Register
I/O Type
Units
I/O Range
Holding Register
Representation
Terminal
Block Labels
Gateway or
DX85
Any Node
Min. Val-
ue
Max. Val-
ue
Min.
(Dec.)
Max.
(Dec.)
1
1
1 + (Node# × 16)
Discrete IN 1
-
0
1
0
1
DI1
2
2
2 + (Node# × 16)
Discrete IN 2
-
0
1
0
1
DI2
3
3
3 + (Node# × 16)
Discrete IN 3
-
0
1
0
1
DI3
4
4
4 + (Node# × 16)
Discrete IN 4
-
0
1
0
1
DI4
5
5
5 + (Node# × 16)
Analog IN 1
mA
V
0.0
0.0
20.0
10.0
0
65535
AI1
6
6
6 + (Node# × 16)
Analog IN 2
mA
V
0.0
0.0
20.0
10.0
0
65535
AI2
7
7
7 + (Node# × 16)
Reserved
8
8
8 + (Node# × 16)
Device Message
9
9
9 + (Node# × 16)
Discrete OUT 1
-
0
1
0
1
DO1
10
10
10 + (Node# × 16)
Discrete OUT 2
-
0
1
0
1
DO2
11
11
11 + (Node# × 16)
Discrete OUT 3
-
0
1
0
1
DO3
12
12
12 + (Node# × 16)
Discrete OUT 4
-
0
1
0
1
DO4
13
13
13 + (Node# × 16)
Analog OUT 1
mA
V
0.0
0.0
20.0
10.0
0
65535
AO1
14
14
14 + (Node# × 16)
Analog OUT 2
mA
V
0.0
0.0
20.0
10.0
0
65535
AO2
15
15
15 + (Node# × 16)
Control Message
16
16
16 + (Node# × 16)
Reserved
Some analog I/O models may use milliamps or voltage, depending on the model. Check the models table (on page 1) of your product's
data sheet to determine which model you have.
Specifications
Radio and General
Range
900 MHz: Up to 4.8 kilometers (3 miles)
2.4 GHz: Up to 3.2 kilometers (2 miles)
Power
Requirements: +10 to 30V dc (Outside the USA: +12 to
24V dc, ±10%). (See UL section below for any applica-
ble UL specifications)
Consumption: Less than 1.4 W (60 mA) at 24V dc
SureCross DX80 Node
6
