Banner K80 Pick-to-Light EZ-LIGHT - Manual (Page 6)

Dimensions
K50L K80L
M30x1
(mounting nut included)
max. torque
4.5 Nm (40 lbf in)
½ -14 NPSM
internal threads
50.0 mm
(1.97")
36.8 mm (1.45")*
20.0 mm (0.79")
11.0 mm (0.43")
Ø15.6 mm (Ø0.61")
*For push-button models, this dimension is 44.2 mm (1.74
in)
72.5 mm
2.85"
41.3 mm
1.63"
Ø50.0 mm
1.97"
7.9 mm
0.31"
65.0 mm
2.56"
80.8 mm
3.18"
65.0 mm
2.56"
7.6 mm
0.30"
Wiring
NOTE: Cabled hookups only are shown. Wiring is functionally identical for cabled and quick-disconnect mod-
els.
NPN (Sinking) Output Models PNP (Sourcing) Output Models Wiring Key Pinout
12-30V dc
Job Light
Enable < 1.0V dc
–
+
1
3
2
4
Load
12-30V dc
Job Light
Enable > 7V dc
–
+
1
3
2
4
Load
1 = Brown
2 = White
3 = Blue
4 = Black 2
3
4
1
EZ-LIGHT® K50 and K80 Series Pick-to-Light Sensors
