Page 6
I/O
Modbus Holding Register
I/O Type
Units
I/O Range
Holding Register
Representation
Terminal
Block Labels
Gateway
Any Node
Min.
Max.
Min.
(Dec.)
Max.
(Dec.)
1
1
1 + (Node# × 16)
Discrete IN 1
-
0
1
0
1
DI1
2
2
2 + (Node# × 16)
Discrete IN 2
-
0
1
0
1
DI2
3
3
3 + (Node# × 16)
Analog IN 1+
mA / V
0.0
20.0 /
10.0
0
65535
A1+
4
4
4 + (Node# × 16)
Analog IN 2+
mA / V
0.0
20.0 /
10.0
0
65535
A2+
5
5
5 + (Node# × 16)
Analog IN 3+
mA / V
0.0
20.0 /
10.0
0
65535
A3+
6
6
6 + (Node# × 16)
Analog IN 4+
mA / V
0.0
20.0 /
10.0
0
65535
A4+
7
7
7 + (Node# × 16)
Reserved
8
8
8 + (Node# × 16)
Device Message
9
9
9 + (Node# × 16)
Discrete OUT 1
-
0
1
0
1
DO1
10
10
10 + (Node# × 16)
Discrete OUT 2
-
0
1
0
1
DO2
...
15
15
15 + (Node# × 16)
Control Message
16
16
16 + (Node# × 16)
Reserved
Specifications
Radio and General
Range
900 MHz: Up to 4.8 kilometers (3 miles)
2.4 GHz: Up to 3.2 kilometers (2 miles)
Transmit Power
900 MHz: 21 dBm conducted
2.4 GHz: 18 dBm conducted, less than or equal to 20
dBm EIRP
900 MHz Compliance (150 mW Radios)
FCC ID TGUDX80 - This device complies with FCC
Part 15, Subpart C, 15.247
IC: 7044A-DX8009
2.4 GHz Compliance
FCC ID UE300DX80-2400 - This device complies with
FCC Part 15, Subpart C, 15.247
ETSI/EN: In accordance with EN 300 328: V1.7.1
(2006-05)
IC: 7044A-DX8024
Spread Spectrum Technology
FHSS (Frequency Hopping Spread Spectrum)
Link Timeout
Gateway: Configurable
Node: Defined by Gateway
Power
Requirements: +10 to 30V dc or +3.6 to 5.5V dc low
power option (Outside the USA: +12 to 24V dc, ±10%
or +3.6 to 5.5V dc low power option)
Consumption: Less than 1.4 W (60 mA) at 24V dc
Housing
Polycarbonate housing and rotary dial cover; polyester
labels; EDPM rubber cover gasket; nitrile rubber, non-
sulphur cured button covers
Weight: 0.26 kg (0.57 lbs)
Mounting: #10 or M5 (SS M5 hardware included)
Max. Tightening Torque: 0.56 N·m (5 lbf·in)
Antenna Connection
Ext. Reverse Polarity SMA, 50 Ohms
Max Tightening Torque: 0.45 N·m (4 lbf·in)
Interface
Indicators: Two bi-color LEDs
Buttons: Two
Display: Six character LCD
Wiring Access
Four PG-7, One 1/2-inch NPT, One 5-pin Euro-style
male connector
SureCross DX80 FlexPower Node
6
