Specifications

Supply Voltage and Current

12 to 30V dc (10% max. ripple) at less than 62 mA for
the emitter and 50 mA for the receiver (exclusive of
load)

Supply Protection Circuitry

Protected against reverse polarity

Sensing Range

2 m (6.5 ft) with 2x excess gain remaining

Sensing Height

100 mm (3.9 in), 225 mm (8.9 in), 300 mm (11.8 in), or
375 mm (14.8 in), depending on emitter and receiver
models

Beam Spacing

25.0 mm (0.98 in)

Sensing Resolution

35 mm (1.4 in) minimum diameter

Output Configuration

Receivers have one solid-state dc output, programma-
ble for light or dark operate:
Models PVA...N6R have current sinking (NPN) open-
collector transistor
Models PVA...P6R have current sourcing (PNP) open-
collector transistor

Output Rating

150 mA maximum
OFF-state leakage current: less than 2 microamps
ON-state saturation voltage: less than 1V dc at 10
mA and less than 1.5V dc at 100 mA

Output Protection

Protected against false pulse on power-up and continu-
ous overload or short circuit of output

Status Indicators

Emitter: Green—power ON/OFF; Red—frequency se-
lected
Receiver: Green—power ON/OFF; Yellow—output
state
Emitter and Receiver: Two highly visible job lights
turn ON and OFF in response to an external signal to
the white wire. Job lights may be configured for steady
or flashing green.

Construction

Black painted aluminum housing; acrylic lenses; PBT
end caps; thermoplastic elastomer programming switch
cover; stainless steel mounting brackets and hardware

Connections

Emitter: 3-conductor PVC-jacketed 2 m (6.5 ft) cable
which is either unterminated or terminated with a 4-pin
Euro-style quick-disconnect connector, depending on
model. Cable diameter is 3.3 mm (0.13 in).
Receiver: 4-conductor PVC-jacketed 2 m (6.5 ft) cable
which is either unterminated or terminated with a 4-pin
Euro-style quick-disconnect connector, depending on
model. Cable diameter is 3.3 mm (0.13 in).

Environmental Rating

NEMA 2; IEC IP62

Operating Temperature

0 °C to +50 °C (+32 °F +122 °F)

Maximum Off-axis Misalignment

See

Figure 3. Maximum Off-Axis Misalignment

on page

Certifications

Output Response Time

Sensor Size

Standard

With Crosstalk from Adjacent Units

100 mm

20 ms

30 ms

225 mm

40 ms

60 ms

300 mm

52 ms

78 ms

375 mm

64 ms

96 ms
