Model 3 Description Array Length / # Beams Job Light Input 4 Receiver Output
PVA225N6 Emitter/Receiver Pair
225 mm (9 in) Long, 5
Beams
0V dc NPN (Sinking) PVA225N6E Emitter
PVA225N6R Receiver
PVA225P6 Emitter/Receiver Pair
+5 to 30V dc PNP (Sourcing) PVA225P6E Emitter
PVA225P6R Receiver
PVA300N6 Emitter/Receiver Pair
300 mm (12 in) Long, 13
Beams
0V dc NPN (Sinking) PVA300N6E Emitter
PVA300N6R Receiver
PVA300P6 Emitter/Receiver Pair
+5 to 30V dc PNP (Sourcing) PVA300P6E Emitter
PVA300P6R Receiver
PVA375N6 Emitter/Receiver Pair
375 mm (15 in) Long, 16
Beams
0V dc NPN (Sinking) PVA375N6E Emitter
PVA375N6R Receiver
PVA375P6 Emitter/Receiver Pair
+5 to 30V dc PNP (Sourcing) PVA375P6E Emitter
PVA375P6R Receiver
NOTE: Cable diameter is 3.3 mm (0.13 in) on all models.
Overview
The PVA Series Parts Verification Array is a simple, easy-to-use light screen suited to many part assembly and object detection applica-
tions.
The PVA has two components: an emitter and a receiver. The receiver's solid-state output interfaces to a system controller, which is pre-
programmed by a supervisor for a specific sequence of tasks. Mounted so that the beams stretch across each bin in an assembler’s work
station, the PVA then signals the assembler (by means of easy-to-see job lights) which bins contain items to be picked in a given opera-
tion and in what order they should be picked.
As the assembler reaches into each bin, the system senses if the correct part has been taken, then signals the next bin in the sequence.
The system may be wired to signal an alarm for the assembler and/or a supervisor in the event an incorrect part is selected.
The major benefit of a PVA-driven system is increased efficiency, due to simplified job training, increased quality control (no skipped
components), and reduced rework and inspections. The PVA speeds the resumption of work after breaks and other distractions. And it is
ideal for multilingual workplaces where communication may be an issue.
3 Only cabled models (2 m (6.5 ft) unterminated integral cable) are listed. For 2 m (6.5 ft) pigtail with Euro-style Quick-disconnect fitting, add "Q" to the model number (for example,
PVA100N6Q).
4 See Configuration on page 5
PVA Pick-to-Light Array
