Metrohm 909 UV Digester - Manual (Page 56)

11.1 Scope of delivery
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
48 ￭￭￭￭￭￭￭￭
909 UV Digester
Qty. Order no. Description
1 6.2745.100 UV protective shield
For 909 UV Digester.
Material: Plexiglas (PMMA)
Material remark: Protective shield
Material 2: Aluminum
Material remark 2: Mounting ring
Height (mm): 212
Outer diameter (mm): 160
Inner diameter (mm): 140
1 6.2804.090 UV mercury vapor lamp
Medium pressure mercury vapor lamp for 909 UV Digester
Material: Quartz
Outer diameter (mm): 16 ... 18
Length (mm): 137 ... 139
1 6.2225.000 UV warning plate
For 909 UV Digester
Material: PVC
Width (mm): 100
Height (mm): 92
1 6.2122.0x0 Power supply cable with IEC 60320 line
socket, type C13
Cable plug according to customer requirements.
Switzerland: SEV 1011, Type 12
6.2122.020
Germany, …: CEE 7, Type VII
6.2122.040
USA, …: NEMA 5-15, Type 498
6.2122.070
Length: 1.5 m
1 8.909.8001EN 909 UV Digester Manual
