3.4 Preparing and connecting the temperature sensor
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
16 ￭￭￭￭￭￭￭￭
909 UV Digester
Figure 15 Inserting the storage vessel for the temperature sensor
into the holder
For storing the temperature sensor between digestion processes.
2 Insert the temperature sensor equipped with the temperature plug
and spacer into the storage vessel.
Connecting
Proceed as follows:
1 Insert the plugs for the temperature sensor into the Temp. sockets.
Figure 16 Connecting a temperature sensor
