Page 30
2.5 Device connection at the USB
24
Titrando Installation Instructions
2.5.3 Connecting a USB Sample Processor / Robotic Titrosampler
A USB Sample Processor or a Robotic Titrosampler can be controlled
by Touch Control or PC Control/tiamo.
Use the 6.2151.000 cable to connect the USB connection of the Ti-
trando (type A) with the controller socket of the USB Sample Proc-
essors / Robotic Titrosampler.
Fig. 16: Titrando –USB Sample Processor
Start the PC Control/tiamo software or switch on the Touch Control.
The USB Sample Processor / Robotic Titrosampler will be recog-
nized automatically and entered in the device list of PC Con-
trol/tiamo or Touch Control.
Configure the USB Sample Processor / Robotic Titrosampler in the
device manager or the configuration dialog as described in the In-
structions for Use for PC Control / Touch Control or tiamo respec-
tively.
2.5.4 Connecting additional Titrandos or Dosing Interfaces
With the Touch Control or the PC Control software you can control up to
three Titrandos or Dosing Interfaces. The tiamo software allows to ex-
pand the system with practically any number of control devices.
Use the 6.2151.000 cable to connect the USB connection of the first
Titrando / Dosing Interface (type A) with the controller socket of the
second Titrando / Dosing Interface.
Fig. 17: Titrando – Titrando/Dosing Interface
Switch on the Touch Control or start the PC Control/tiamo software.
The Titrando / Dosing Interface will be recognized automatically and
entered in the device list of PC Control/tiamo or Touch Control.
