Lift float kit – Bush Hog RMB 1865 User Manual
Page 63
BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL
93-1-57
APRIL, 2011
LIFT FLOAT KIT
REF.
PART
NO.
NO.
DESCRIPTION QTY.
1
8126044
Accumulator 1l 25 Bar Pc
1
2
8126318
Bracket Float Kit
1
3
G2410380
Adaptor 3/8 Bsp X M22 M-M
1
4
8650322
M22 Bonded Seal
1
5
8650103
Seal,3/8bsp Bonded
4
6
08.200.01
Valve, Ball
1
7
8581209
Union 3/8 Bspm X 3/8 Bspm
1
8
8123041
Disc, Restrictor-1.5mm Orifice
1
9
8116011
Spring .275x23 Swgx5/8 Lg
1
10
8581346
Adaptor Rest. Body 3/8mm
1
11
08.958.18
Hose 3/4" Jic Fs/F90 1000
1
12
11.068.69
Adaptor-Tee 3/8f-3/8m+3/8m
1
13
9163006
Nyloc Nut M12
2
14
9313056
Capscrew M12-P1.75- 25mm Pl5
2
15
8581221
Adaptor 3/8"Bsp F X 3/4" Jic M
2
16
8581117
Connector, 3/8 Bsp 90deg.
1
