BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL
93-1-7
APRIL, 2011
HEAD, ANGLING
REF. PART
NO. NO. DESCRIPTION QTY.
1 0423556 Spring Dowel 5/8in X 3-1/2in 1
2 05.281.18 Flat Washer 30mm - Plated 2
3 08.297.04 Bushing 37 X 30 X 30 4
4 0901121 Grease Nipple,1/8 2
5 42646.03 Radius Arm 1
6 42646.04 Radius Arm 1
7 21801.01 Slave Link Casting 1
8 42648.01c Jaw Plt Cast 30.0 Pivots 1
9 42649.01 Pivot Tube 1
10 42684.01 Pin 1
11 42684.05 Pin - 30mm X 116 Lg 1
12 43055.09 Hose Brkt 1.5/16 Jic 1
13 7198333 Hose Tray 1
14 9100028 Nut 2
15 9100105 Flatwasher 10.5 X 23.5 X 2.0 4
16 9163005 Nut M10 Nyloc 6
17 9200023 Bolt Ht M16 X 1.5p X 55lg 1
18 9200028 Bolt 1
19 9213205 Bolt M10 X 100 1
20 9313065 Capscrew M 10-P1.5 X 30mm Pl5 4
21 9313075 Capscrew M 10-P1.50 X 35mm 5 1
22 0425540 Roll Pin M5 X 40 2
23 02971717 Roll Pin M6 X 50 1
24 8629218 Seal, 30 X 40 X 4 4
