BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL
93-1-9
APRIL, 2011
PILLAR, RH
REF. PART
NO. NO. DESCRIPTION QTY.
1 0901121 Grease Nipple, 1/8 6
2 45192.10 RH Pillar 1
3 45202.04 Pin W/A - Slew Rod 1
4 45202.07 Pin W/A - Left Ram Base 1
5 45264.03 Main Pivot Pin 1
6 45271.01 Pivot Pin 2
7 45298.01 Thrust Washer 75 X 41 X 5 1
8 45416.01 Screw, Special M12 X 40 Drilled 1
9 9100206 Lockwasher, 12mm 1
10 9163005 Nut M10 Nyloc 2
11 9163006 Nut Nyloc M12 2
12 9213136 Capscrew M 12-P1.75- 65mm 1
13 9313075 Capscrew M 10-P1.50- 35mm 2
14 9313076 Capscrew M 12-P1.75- 35mm 1
15 9501255 Cotter Pin 4mm X 25mm 1
