BUSH HOG / LAND MAINTENANCE REPAIR PARTS MANUAL
93-1-37
APRIL, 2011
CABLE ACV
REF. PART
NO. NO. DESCRIPTION QTY.
1 8130466 Control Valve 4 Spool 1
2 8130124 Relief Valve Cartridge 1
3 8116011 Spring .275x23 Swgx5/8 Lg 2
4 8130156 Relief Valve Housing 1
5 8130083 Body, Relief Valve 1
6 8650103 Seal, 3/8 Bsp Bonded 11
7 8650104 Seal, 1/2 Bsp Bonded 1
8 8017050 Control Hd/Cable Assy-3.5m 4
9 8650102 Seal, 1/4 Bsp Bonded 3
10 8130067 Restrictor 1/4-3/8 Bsp 1
11 6000113 Adaptor 3/8 Bsp M/M 1
12 05.123.01 Adaptor 1/2 X 3/8 Bsp M/M 1
13 8581115 Adaptor, 1/4 X 3/8 Bsp Male 1
14 8581254 Tee Adaptor 1/4 Bsp M-F-M 1
15 04.282.71 Stud M6 X 233 Plated 3
16 7650307 Arm Rest Brkt W/A 1
17 1290368 Decal, Control 1
18 1290541 Decal-Slew Sma1046 1
19 8581209 Union 3/8 Bspm X 3/8 Bspm 1
20 8581214 Restrictor Adaptor 1/4" Bsp 1
21 8123044 Restrictor Disc, 1.8mm Orifice 1
22 9343022 Shcs Metric 5-P0.8 - 12mm Pl9 8
23 9213134 Bolt 3
24 9163004 Nut Nyloc M8 3
25 9313034 Capscrew M 8-P1.25- 16mm 2
26 9113004 Nut 8mm-P1.25 Pl 2
27 04.056.25 Tee 1/2 - 1/2 - 1/4 Fmm 1
28 8581117 Connector,3/8 Bsp 90deg. 1
29 9163003 Nut M6 Nyloc 6
30 1290338 Decal,Rotor Control Valve 1
31 8124120 Restrictor 3/8bsp-9/16jic 1
32 8124121 Restrictor 3/8 Bsp-9/16 Jic 2
33 8124118 Restrictor 3/8bsp-9/16jic 1
34 8124125 Restrictor 3/8" Bsp-9/16 Jic 1
35 05.835.11 Adaptor,Swivel 90-1/4 X 9/16 Jic 3
36 8581341 Adaptor 1/4 Bspfx 9/16 Jicm 2
37 8581220 Adaptor 1/2 Bspf-7/8jic M 1
