User’s Guide — 59
TTL WIRES
Find conduit fill %
C
FILL 36.1
COND %
Find actual fill area
C
FILL 0.6711
TTL WIRE AREA
Find remaining area
C
REM 0.0717
WIRE AREA
* NOTE: See “Settings” for a list of
Permanent Values/settings. Changing
these settings may affect your calculations.
Error Codes
The error codes for the ElectriCalc Pro
are listed below (Note: To clear an
error, perform an All Clear
S x ):
Error Description
1
Display register overflow
(Answer too large to fit display)
2 Invalid or out-of-scale entry
3 PF or EFF calculated above 100%
4 Conduit Size beyond limits of table
5 Unable to calculate VDWire Size
(Amps/Length too high)
8 Invalid HP entry per NEC table
9 Entered or calculated more than 15
different wires sizes
11 Temperature setting out of range for
wire computation.
