User’s Guide — 57
Enter wire size
6 w
AWG 6 CU
WIRE SIZE
Enter # THHN
11 t
THHN 11.
WIRES
Find conduit size
C
IMC 1.25 in
COND SIZE
Finding Number of Wires in Ex-
isting Conduit — Same Size,
Various Types
Find the maximum number of #10
THHN copper wires that can be pulled
through an existing 3” EMT conduit.
How many XHHW wires? How many
THW wires?
Steps Keystrokes Display
Clear calculator
o o
0.
Enter cond. type
1 S C
EMT nonE
COND
Enter wire size
1 0 w
AWG 10 CU
WIRE SIZE
Enter conduit size
3 C
EMT 3.00 in
COND SIZE
Find max THHN #
t
THHN 167.
TTL WIRES
Find max XHHW#
X
XHHW 145.
TTL WIRES
Find max THW #
T
THW 145.
TTL WIRES
