16 — ElectriCalc Pro
l — Length
Enters or calculates the length of a run
for voltage drop computation.
Displays: FEET or MET.
NOTE: Units of length can be set to
Feet or Meters by use of the Prefer-
ence function
S ÷.
S l — Wire Resistance
Displays the actual resistance per
1,000 feet of the wire size in
w based
on NEC Chapter 9, Table 8.
Displays: OHMS WIRE.
Ground Function Keys
G — Ground
An output-only key used to find the
grounding electrode conductor size for
AC systems based on NEC Table
250-66 and an entered or calculated
service-entrance conductor (largest
size). Only actual wire sizes are con-
sidered valid entries.
♦ First Press
Calculates the copper grounding elec-
trode conductor size if you have en-
tered a valid wire size.
Displays: GRND CU WIRE SIZE.
