Example: Different Format Sync
Using the [In] and [Out] keys, find the
offset between 1:00:00:00 30 NDF
Time Code and 95:00 Ft/Frms of
35mm film. Then store this offset in
[Sync] and find the matching film edit
points for the following Time Codes.
TC Edit Point #1 — 1:11:30:05
TC Edit Point #2 — 1:14:43:22
TC Edit Point #3 — 1:15:01:09
Step Keystrokes Display
Clear calc. [On/C] [On/C] 0.
Select 30 NDF [30 NDF] 0:00:00:00
Enter TC ref. point 1[:] [:] [:] [In] 1:00:00:00
Enter Film ref. pt. [35mm] 95 [:] [Out] 95:00
F/F
Find offset [Dur] –5305:00
F/F
Store as sync [Stor] [Sync] –5305:00
F/F
Ent. TC edit pt. #1* [30 NDF] 1113005 1:11:30:05
Find Film edit pt. [Sync] 1130:04
F/F
Ent. TC edit pt. #2 1 1 4 4 3 2 2 1:14:43:22
Find Film edit pt. [Sync] 1420:10
F/F
Ent. TC edit pt. #3 1 1 5 0 1 0 9 1:15:01:09
Find Film edit pt. [Sync] 1446:15
F/F
* You only need to convert to the “A” source’s for-
mat the first time. Subsequent conversions be-
tween the two media formats is automatic.
36 – Frame Master ® II
