pMT INsTaLLaTION INsTRUCTIONs
These installation instructions are split into five sections. Each section provides a comprehensive description
of installation for all vehicle applications. The five sections are:
• SECTION 1 : Mounting the Cradle
• SECTION 2 : Installing the Pyrometer and the PCH Board
• SECTION 3 : Installing the OBDII Adapter
• SECTION 4 : Installing the Power Wire
• SECTION 5 : Proper docking and removal of the PMT from the Cradle
seCTION 1: MOUNTING THe CRaDLe
In this section you will decide where to mount the PMT Cradle, so you are essentially choosing the location
for the PMT inside the vehicle cab. First, decide which mounting style you will choose for the PMT; we offer
three different styles of mounting:
1. Custom A-Pillar mounting (most recommended)
2. Dash mounting
3. Windshield mounting
The following mounting instructions outline how to mount the PMT, explaining each mounting style
individually.
