Bird 8640 Series Moduload RF Load Resistor

30

Load

ITEM
NO.

DESCRIPTION

QTY

PART NO.

Load Complete

8645
8646

1

8745-101-1
8746-101

1

Resistor

1

8755-027

2

Outer O-Ring

1

8410-009

3

Water Chamber

1

8755-014

4

Water Chamber Inner O-Ring

1

5-099

5

Fitting, 90°

1

8640-089

5A

Fitting, Straight, consisting of:

Bushing
Nipple

1
1

5-489-1
5-490-1

6

Screw

1

⁄

4

-20 x 2-

1

⁄

2

inch

6

1121-2508-00

7

Resistor Sleeve

1

8755-026

8

Sleeve O-Ring

1

8110-059

9

Inner Flow Tube

1

8755-025

9A

Outer Flow Tube

1

8755-024

10

Resistor Ground Cap

1

8755-005

11

Center Conductor Assembly

8645
8646

1

8755-007
8756-003

12

Outer Conductor Assembly

8645
8646

1

8755-004
8756-002

15

Center Conductor O-Ring

1

5-1127

16

Screw

1

⁄

4

-20 x 1-

1

⁄

2

inch

6

1121-1808-00

17

Inner O-Ring

1

5-567
