DIMENSIONAL DATA - DOUBLE ROW BVC MODELS
- 7 -
DIMENSIONS - Inches (mm)
DOUBLE ROW
MODEL
LENGTH
L
MOUNTING LEG CENTRES
M1
M2
M3
M4
22
039
83 1/8 (2111)
86 1/8 (2188)
76 1/8 (1934)
-
-
22
045
83 1/8 (2111)
86 1/8 (2188)
76 1/8 (1934)
-
-
22
049
97 1/8 (2467)
86 1/8 (2188)
90 1/8 (2289)
-
-
22
054
97 1/8 (2467)
86 1/8 (2188)
90 1/8 (2289)
-
-
23
058
123 1/4 (3131)
86 1/8 (2188)
116 1/4 (2953)
-
-
23
067
123 1/4 (3131)
86 1/8 (2188)
116 1/4 (2953)
-
-
23
073
144 1/4 (3664)
86 1/8 (2188)
137 1/4 (3486)
-
-
23
081
144 1/4 (3664)
86 1/8 (2188)
137 1/4 (3486)
-
-
23
086
183 (4648)
86 7/16 (2196)
176 1/4 (4477)
-
-
23
096
183 (4648)
86 7/16 (2196)
176 1/4 (4477)
-
-
24
112
243 (6172)
86 7/16 (2196)
236 5/16 ( 6002)
116 3/16 (2951)
-
24
126
243 (6172)
86 7/16 (2196)
236 5/16 ( 6002)
116 3/16 (2951)
-
24
137
243 (6172)
86 7/16 (2196)
236 5/16 ( 6002)
116 3/16 (2951)
-
25
158
303 (7696)
86 7/16 (2196)
296 5/16 (7526)
116 3/16 (2951)
176 3/16 (4475)
25
172
303 (7696)
86 7/16 (2196)
296 5/16 (7526)
116 3/16 (2951)
176 3/16 (4475)
26
190
363 (9220)
86 7/16 (2196)
356 5/16 (9050)
116 3/16 (2951)
236 3/16 ( 5999)
26
206
363 (9220)
86 7/16 (2196)
356 5/16 (9050)
116 3/16 (2951)
236 3/16 ( 5999)
